x930 Series Installation Guide for Virtual Chassis Stacking
175
4. Check the display for the following:
Switch ID 1 is the master switch.
The other ID entries are the provisioned member switches. There
should be one entry for each member switch that will be in the
stack. If the table does not include these fields, perform the
SWITCH PROVISION command in “Configuring the Master Switch
- Part II” on page 173.
The master switch should have the priority 1 if you performed the
STACK PRIORITY command in “Configuring the Master Switch -
Part I” on page 171.
5. Enter the SHOW RUNNING-CONFIG INTERFACE command to view
the port configurations on the master switch and provisioned member
switches. Confirm that the correct Gigabit ports have the STACKPORT
command, designating them as the stack trunk:
Figure 81. SHOW RUNNING-CONFIG INTERFACE Command on the
Master Switch
6. Go to “What to Do Next,” next.
awplus# show running-config interface
interface port1.0.1-1.0.23
switchport
switchport mode access
stack enable front-panel-ports
!
interface port1.0.1-1.0.8
stackport
!
interface port1.0.27-1.0.28
switchport
switchport mode access
!
interface port2.0.1-2.0.23
switchport
switchport mode access
!
interface port2.0.1-2.0.8
stackport
!
interface port2.0.27-2.0.28
switchport
switchport mode access
.
.
Trunk ports on the
master switch
Trunk ports on a
provisioned member
switch
