194
ML-5120A
Specications
Laser
Controller
Active heat control function
Laser output control by detecting the temperature of the
processing part
<Note>
Eective only when using with the output unit FOCH-30B
series.
Operating
Environment
Ambient temperature *1
Without cooler: 10 to 35°C
With cooler (option): 10 to 40°C
Ambient humidity 20% to 80% RH (non-condensing)
Temperature during transport or
storage
-10 to 50°C
Humidity during transport or
storage
20% to 90% RH
Vibration during transport 4.9 m/s
2
(0.5 G) max.
Impact during transport 49 m/s
2
(5 G) max.
Vibration during operations 10 to 60 Hz: 0.98 m/s
2
(0.1 G) max.
Intermittent vibration during
operations
Less than 2 Hz: 4.9 m/s
2
(0.5 G) max.
Others
Mass 120 kg or less
Dimensions
Without cooler: 696 (H) × 400 (W) × 900 (D) mm
With cooler (option): 696 (H) × 400 (W) × 971 (D) mm
Noise level
A; Weighted
equivalent
continuous sound
pressure level
75 dB (A) max.
C; Sound pressure
level
0.3 Pa max.
