102 Intellex
®
LT Digital Video Management System
Controlling Image Display
Use one of the following methods:
• Click the Seq button. Sequencing stops and cameras display
in the previous format.
• Click any format button (1x1, 2x2, 3x3 or 4x4). Cameras
display in the appropriate format.
• Click any camera button (1–16). The selected camera
displays in the single-pane format.
Live Monitor (Optional)
If an optional live monitor is installed, the unit displays all live
images continuously on the optional monitor. Live display
commands, such as selecting a camera or a screen format, appear
immediately on the optional monitor.
Dome Controller
(Optional)
If a dome controller (Sensormatic VM16 or American Dynamics
ADTT16) is connected, you can use it to display a specific camera,
change the display format (1x1, 2x2, 3x3, 4x4) or sequence cameras
(live mode only). Refer to the dome controller instructions for more
information.
Unit Schedule
Images from cameras that are disabled in the schedule will not
display. This helps the user monitor cameras that are being
recorded. For more information, see Schedule Setup on page 45.
