70 Intellex
®
LT Digital Video Management System
Schedule Setup
d. Repeat these steps until you are ready to enclose the target
area.
e. Use one of the following methods to enclose the target area:
• Set at least three endpoints. Then hold the mouse pointer
over the last endpoint and double-click the button. The
boundary lines disappear and the target area is defined
by a semitransparent grid.
• Move the mouse pointer to the starting point and click
the mouse button. The boundary lines disappear and the
target area is defined by a semitransparent grid.
Click Apply to apply the configuration for this filter as shown and
close the Light Change screen. Click Cancel to cancel the changes
and return to the previous screen. Click Help to display online help
for this screen.
Motion Detection Use the Motion Detection screen to configure the target area for the
motion detection filter. Once configured, the filter is triggered
whenever movement occurs in the target area.
After you select the Motion Detection filter and click the Setup
button, the Motion Detection screen appears.
Motion Detection: (camera name) — Indicates the camera name.
Image Area — This area of the screen displays a camera image and
provides a reference when configuring the filter.
Active Zone — Use the following options to configure the target
area. This area can be nearly any shape or size.
Activate — Use this option to activate a specific target area.
Deactivate — Use this option to deactivate a previously acti-
vated target area.
Restore — Click to restore the target area to its dimensions
before any changes.
Clear — Click to erase all of the targets in the active zone.
All — Click to activate all of the targets in the image area.
Undo — The unit stores each target area change in memory.
Click to remove the last change to the target area.
