66 Intellex
®
LT Digital Video Management System
Schedule Setup
1. Click down arrow. A list of filters appears.
2. Click the desired filter. Select None to disable any previously
configured filters.
3. Click Setup to configure the filter (see Live Filter
Configuration on page 68).
Setup — Select a filter for this segment; then click Setup to
configure it (see Live Filter Configuration on page 68.
Select another segment for configuration. Otherwise, click OK to
accept the configuration for this segment as shown, and return to
the Weekday, Weekend or Holiday screen. Click Cancel to cancel
the changes and return to the Weekday, Weekend or Holiday screen.
Click Help to display online help for this screen.
Configuring an Alarmed
Segment
Use the Alarmed Segment screen to configure the pre-alarm record
quality and duration for the segment as well as the live filter.
1. Define the segment (see Working with Schedule Segments on
page 57).
2. Use one of the following options to display the Alarmed
Segment screen:
• Double-click the segment to configure.
• Select the segment to configure; then click Setup.
• Select the segment to configure; then access the custom
schedule popup menu (see Custom Schedule Popup Menu
on page 59
); then select Setup.
Alarmed segment: (camera name) from hh:mm to hh:mm. —
Indicates the camera name and the segment’s start and end times.
Pre-Alarm Quality — Select the record quality for the pre-alarm
images recorded during this segment. The default is Normal.
NOTE: This quality setting only affects pre-alarm images. To set
the record quality of alarm images, refer to Alarm
Operations on page 141.
Super — Record images at the highest image quality. Since the
unit uses the lowest level of compression, this setting requires
the highest amount of storage space.
