12 Intellex
®
LT Digital Video Management System
Installing the Intellex Unit
To add a loop-through device, connect the cable from the loop-
through device to the appropriate Camera Out connector. Then
select Hi-Z for the camera in the Cameras portion of the Setup
Options screen.
To remove a loop-through device, disconnect the cable from the
appropriate Camera Out connector. Then select 75 Ohms
termination for the camera in the Cameras portion of the Setup
Options screen.
Alarms CAUTION: Protect the unit against lightning. If a portion of a
cable is installed outside of a building, the entire
cable is vulnerable to lightning. Therefore, install
protection devices on all vulnerable cables.
The alarm connectors include pins for mechanical or TTL/CMOS
standard alarm inputs and outputs. Connect up to 16 alarm inputs
and 16 alarm outputs. (See Alarm Connectors on page 170 for specific
pin assignments and additional information.)
Video Out The Video Out connector provides continuous live video, even
during image playback. Connect this output to the video input of
an optional live monitor (NTSC/EIA or PAL/CCIR).
Keyboard If installing a keyboard, plug it into the keyboard connector.
Printer Connect this output to a parallel printer that supports graphics.
Com2 Connect this input to a dome controller (Sensormatic VM16 or
American Dynamics ADTT16) using an external interconnect
module (EIM). Refer to the dome controller documentation for
more information.
SCSI-3 NOTE: Even though an external SCSI terminator is not required
on this unit, it may be required on the optional data
storage device.
To connect an optional storage device:
1. Disconnect both ribbon cables from connectors 19 and 21 on
the rear panel (see Rear Panel on page 8).
2. Connect the optional data storage device to connector 16 on
the rear panel.
3. Reconnect both ribbon cables to connectors 19 and 21 on the
rear panel.
