178 Intellex
®
LT Digital Video Management System
Installation and use of Intellex Accessories
3. Go to Windows Control Panel by clicking on Start, Settings,
Control Panel.
4. Double-click on the System icon. Then click on the Device
Manager tab in the System Properties window.
5. One of the items in the device tree will be CDROM. Click on
the + sign next to the CDROM item to expand the tree for that
item.
6. The expanded tree will show the device identified by the
manufacturer or model. Click on it to select the device.
7. Click on the Properties button near the bottom of the
window. Then click on the Settings tab.
8. Uncheck the Disconnect and Auto insert notification boxes.
Check the Sync data transfer box.
9. Verify that the only box checked is the Sync data transfer.
10. Click on OK to close the window and save the settings.
11. Click on OK in the System Properties window to close the
window and save the settings.
12. A message will appear asking you if you want to restart your
computer now. Click on NO.
13. Close the Control Panel window by clicking on the X in the
upper right corner.
14. Restart the Intellex by clicking on Start, Shutdown. Select
the Restart option and click on OK.
15. The unit will restart and the Intellex application will begin.
After the initial driver installation it is possible to connect and
disconnect the USB CD-RW drive to or from the Intellex unit
without exiting the Intellex application software. There will be a
warning message each time that the drive is disconnected. Click on
OK to close the warning message.
Intellex USB/RS-232
4-Port Expander-
RDVEXP01
The Intellex USB/RS-232 4-Port Expander can be used to add serial
ports to the Intellex for the recording of text data.
