58 Intellex
®
LT Digital Video Management System
Schedule Setup
5. Click and hold the mouse button. The mouse pointer changes
to .
6. Drag the mouse pointer to the right or left. A box displays the
segment’s new start and end times (24-hour format).
7. When the desired times appear, release the mouse button.
8. To change either the start or end time, click and hold the time
mark. Then drag it until the desired start and end times
appear in the box. (See Changing a Segment on page 58 for
more information.)
9. After defining an active or alarmed segment, configure its
live filter and other settings (see Configuring an Active
Segment on page 64 and Configuring an Alarmed Segment on
page 66).
Changing a Segment NOTE: To change a start time of 00:00 or an end time of 24:00,
define a new segment which starts at 00:00 or ends at
24:00, respectively (see Defining a New Segment on
page 57).
1. Select the appropriate screen: Weekday, Weekend or Holiday.
2. Move the mouse pointer over the start or end time for the
segment to change. The mouse pointer changes to .
3. Click and hold the mouse button.
4. Drag the mouse pointer to the right or left. A box displays the
segment’s new start and end times (24-hour format).
5. When the desired times appear, release the mouse button.
When changing the times of adjacent segments, the unit
chooses the segment that you are enlarging. Then it displays
the times for that segment.
For example, when enlarging an alarmed segment (00:00 to
07:00) that is next to an active segment (07:00 to 18:00), click on
the boundary between the segments (07:00) and drag right. The
unit displays the alarmed segment’s new times, as long as the
boundary stays to the right of 07:00. If the boundary is dragged
left past 07:00, the unit chooses the active segment and displays
the new times for the active segment.
