Technical Specifications
Alarm
Alarm Inputs 16 inputs. Activated by contact
closure or TTL/CMOS signal.
Programmable polarity.
Alarm Outputs 16 outputs. TTL/CMOS
compatible active high. Driven
to +4V and can drive 6mA.
Initialized to inactive low on
power-up.
Alarm Duration Programmable from five
seconds to five minutes.
Display
Color Palette 16,777,216 colors (24 bits)
Gray Shades 256 (8 bits)
Display Controls Mouse-selectable buttons with
indicator lights.
NOTE: Pixel count reflects digital display area and is not affected
by NTSC/PAL signal differences.
Table 3 — Pixel Count by Screen Format
Record Options
Record Mode Linear, Circular
Image Sensitivity High, Normal
Image Quality Super, Normal, Extended
Record
Record Rate NTSC: 60 ips (images per
second), 30 ips, 15 ips, 7.5 ips,
2.5ips, 1ips; PAL: 50 ips, 25 ips,
12.5 ips, 6.25 ips, 2 ips, 0.8 ips
Format
MENU MODE FULL SCREEN
MODE
1x1 640x480 (pixels) 800x600
2x2 320x240 400x300
3x3 213x160 267x200
4x4 160x120 200x150
