54 Intellex
®
LT Digital Video Management System
Schedule Setup
Alarmed — Select this option to define an alarmed segment.
During an alarmed segment, the unit only records images from the
camera when the live filter or alarm input is activated. It records at
the configured record rate and quality. It can also store a selected
amount of pre-alarm images. (See Working with Schedule Segments
on page 57 for information about defining an alarmed segment.)
NOTE: Disabled segments cannot be configured.
Disabled — Select this option to define a disabled segment.
During a disabled segment, the unit does not record or display any
images from the camera. It also ignores any alarms. (See Working
with Schedule Segments on page 57 for information about defining a
disabled segment.)
Setup — After the segments are defined, you can them configure
as active or alarmed. (See Configuring an Active Segment on page 64
and Configuring an Alarmed Segment on page 66 for more
information.)
1. Define the segment (see Working with Schedule Segments on
page 57).
2. Use one of the following options:
• Double-click the segment to configure.
• Select the segment to configure; then click Setup.
• Select the segment to configure; then access the custom
schedule popup menu (see Custom Schedule Popup Menu
on page 59); then select Setup.
Undo — Each time you access these screens, the unit keeps track of
the changes. It remembers up to the last 10 changes on each Custom
Schedule Setup screen (Weekday, Weekend and Holiday).
1. Click this button to undo the last change.
2. Continue clicking to undo additional changes.
3. When the button becomes disabled, you cannot undo any
more changes.
Resolution — This setting lets you choose either 640x240 or
320x240. 640x240 offers higher resolution, but less recording time.
320x240 provides less resolution, but extends the recording time.
The default is 640x240.
