User Manual – Rev BE AMETEK Programmable Power
MX Series 108
The following top-level menu choices can be accessed from the MENU key:
Entry Description
MENU 1
PROGRAM The PROGRAM menu allows output parameters the be
changed.
MEASUREMENTS The MEASUREMENTS screens are not menus in that no
user entries are required.
TRANSIENTS The TRANSIENTS menu allows output transients to be
programmed.
WAVEFORMS The WAVEFORMS menu allows different waveforms to
be selected from the waveform library.
MORE The MORE selection causes the second part of the
MENU screen to be displayed. (MENU 2)
MENU 2
ADVANCED MEAS. The ADVANCED MEAS. screens are for display only. No
user entries are required.
APPLICATIONS The APPLICATIONS menu provides access to the
optional firmware application programs that may be
installed in the MX Series AC source.
SETUP REGISTERS The SETUP REGISTERS menu allows complete
instrument settings and transient list programs to be
saved to nonvolatile memory.
MORE The MORE selection causes the third part of the MENU
screen to be displayed. (MENU 3)
MENU 3
UTILITY The UTILITY menu provides access to less commonly
used setup screens such as those for the GPIB and
RS232C (also applies to USB and LAN) interface
settings, initial startup values, etc.
