Ametek MX Series User Manual

User Manual – Rev BE AMETEK Programmable Power
MX Series 245
8. Top Assembly Replaceable Parts
Note that different generation MX units may use different sub-assemblies.
Check the serial tag on the back of the MX to determine the applicable top
assembly number to determine the correct sub assembly or part required. For
amplifiers, refer to the amplifier serial tag for the relevant amplifier top
assembly part number.
Re f.
CI P / N
Description
Ve n d o r
Qt y
Lo c a t i o n
To p Assembly 7003-427 / 7003-422
A2
7003-421-1
Front Panel Assy. Prog. Osc. AMETEK P P
1
7003-718-2
CPU board assy. All 3 phase MX. AMETEK PP
1
7003-718-4
CPU board assy. MX30-1, MX45-1 only. AMETEK P P
1
7000-723-4
Keyboa r d/ Dis pla y a s sy. AMETEK PP
1
Top Assembly 7003-400
A2
7003-401-1
Front Panel Assy. Prog. Osc. AMETEK P P
1
5100-707-2
CPU / Phase A board assy. AMETEK P P
1
7000-722-2
Phase B/C board assy. AMETEK P P
1
7000-723-1
Keyboa r d/ Dis pla y a s sy. AMETEK PP
1
Top Assembly 7003-427
A1 7003-721-1
PC Assy. RS232 / GPIB / USB AMETEK P P
1
A1 7003-721-2
PC Assy. RS232 / GPIB / USB / LAN AMETEK P P
1
A6 7003-722-1
PC Assy., Low Volt PSU AMETEK P P
1
7003-723-1
Ripple Filter AMETEK P P
1
Top Assembly 7003-422 / 7003-400
A1 7003-703-1
PC Assy. RS232 / GPIB AMETEK P P
1
A1 7003-703-2
PC Assy. RS232 / GPIB AMETEK P P
1
A6 7003-702-1
PC Assy., Low Volt PSU AMETEK P P
1
Top Assembly 7003-427 / 7003-422 / 7003-400
A2 7003-408-1
Front Panel Assy., Auxiliary AMETEK P P
1
A3 7003-715-1
PC Assy., System Interface AMETEK P P
1
A4 7003-701-1
PC Assy., V / I Sense AMETEK PP
1
A1 4 7003-713-1
PC Assy., PWR Interconnect AMETEK P P
1
A1 0 7003-714-1
PC Assy., EMI Filter AMETEK P P
1
A7 7003-418-1
Amplifier Assy., 15kVA AMETEK P P
1
A8 7003-418-1
Amplifier Assy., 15kVA AMETEK P P
1
A9 7003-418-1
Amplifier Assy., 15kVA AMETEK P P
1
B1 241186
Fan, 3", 24VDC
NMB Technology
3110KLO5WB50-P00
1
CB1 270224
Circuit Breaker, 2.5A, 300V
AI RP AX
IELH111-1-61-2-50-D-01-V
1
K1 245235
Relay, 3C, 30A, 24VDC
Deltrol Controls
21014 - 82
1
K8 245235
Relay, 3C, 30A, 24VDC
Deltrol Controls
21014 - 82
1
K2 245236
Relay, 3C, 90A, 24VDC
EE Co n t r o l s
1
