User Manual – Rev BE AMETEK Programmable Power

MX Series 97

Figure 3-24: 7003-426-1 Output Fuse Box

DIMENSIONS 7003-426-1 OUTPUT FUSE BOX:

Parameter

Dimension in Inches

Dimension in mm

Chassis Dimension W x L x H 12.125 “ x 16.125” x 4.125” 308 x 410 x 105 mm

Feet height: 0.875 22 mm

Strain relief hole size: 1.5” diameter 38 mm diameter
