Ametek MX Series User Manual

User Manual – Rev BE AMETEK Programmable Power
MX Series 19
2.1 Electrical
2.1.1 Input
Single Cabinet Models
Parameter
MX22.5
MX3 0
MX4 5
Line Voltage:
(3 phase, 3 wire + ground (PE))
208 VLL ±10%
230 VLL ±10%
380 VLL ±10%
400 VLL ±10%
480 VLL ±10%
600 VLL ±10%
Li n e VA: 2 6 KVA 3 7 KVA 5 3 KVA
Line Current:
89 ARMS @ 187 VLL
79 ARMS @ 207 VLL
49 ARMS @ 342 VLL
46 ARMS @ 360 VLL
38 ARMS @ 432 VLL
30 ARMS @ 540 VLL
116 ARMS @ 187 VLL
105 ARMS @ 207 VLL
64 ARMS @ 342 VLL
60 ARMS @ 360 VLL
50 ARMS @ 432 VLL
40 ARMS @ 540 VLL
175 ARMS @ 1 8 7 VLL
157 ARMS @ 2 0 7 VLL
95 ARMS @ 342 VLL
90 ARMS @ 360 VLL
75 ARMS @ 432 VLL
60 ARMS @ 540 VLL
Line Frequency: 47-6 3 Hz
Efficiency: 85 % (typical) dependent on input line and load
Power Factor: 0.95 (typical) / 0.99 at full power.
Inrush Current:
153Apk @ 208 VLL
146Apk @ 230 VLL
94Apk @ 380 VLL
87Apk @ 400 VLL
73Apk @ 480 VLL
?? Ap k @600VLL
230Apk @ 208 VLL
220Apk @ 230 VLL
130Apk @ 380 VLL
132Apk @ 400 VLL
110Apk @ 480 VLL
88Apk @ 600VLL
Hold -Up Time: > 10 ms
Isolation Voltage: 2200 VAC input to output, 1350 VAC input to chassis

Ametek MX Series Specifications

General

Brand	Ametek
Model	MX Series
Category	Power Supply
Language	English
