User Manual – Rev BE AMETEK Programmable Power

MX Series 244

7.7.3 Flash download Messages

One or more messages may appear during this process. The table below shows

some of the possible message and their meaning.

Message

Description

Re med y

Flash erase complete

Erase operation successful.

Flash erase fail

Firmware download capability not supported

b y CP U board.

Refer to Service Bulletin SB-0043

Flash write fail

Unable to write to flash. This message is

unlikely as it generally is preceded by the

Flash Erase Fail message.

Refer to Service Bulletin SB-0043

Firmware down load fail

Data error. Incorrect checksum read-back

from Flash block. Communication interrupted

or problem with RS232 interface.

1. Check cable connection.

2. Try setting CmdDelay in Flash loader

program to 100 msec and try again.

Table 7-3: Flash Download Messages
