User Manual – Rev BE AMETEK Programmable Power

MX Series 191

5.3.4 GPIB / RS232 or GPIB / RS232 / USB / LAN IO Board

This board assembly is identified as A1. It has the IEEE 488, RS232, and USB

transceivers and optionally an Ethernet interface (-LAN option). USB and LAN

are available on top assembly 7003-427 MX models only. It also has isolators to

provide safety isolation for both interfaces and additional user accessible I/O

lines. Additional user accessible inputs and outputs available through this

assembly are:

• Trigger Input BNC

• Trigger Output BNC

• Function Strobe BNC

• Remote Inhibit (terminal strip)

• External Sync (terminal strip)

• Clock BNC (option)

• Lock BNC (option)

• Output Status (Available on top assembly 7003-427 only.)
