User Manual – Rev BE AMETEK Programmable Power
MX Series 216
6.4.1 Output Cal Series II only
300 VAC Range DC Zero: Program the output to the 300 VAC Range by pressing
and selecting the 300 Range with the shuttle. Program
the output to 0.0 volts and 60 Hz. Go to the OUTPUT
CAL screen, select the VOLT ZERO parameter, and
adjust the output to 0.0 ± 0.005 VDC. Save this value
by pressing the ENTER key.
300 VAC Range High Freq DC Zero: Required for Series II models with –HF option
only. Program the output to the 300 VAC Range by
pressing and selecting the 300 Range with the shuttle.
Program the output to 0.0 volts and 820 Hz. Go to the
OUTPUT CAL screen, select the VOLT ZERO parameter,
and adjust the output to 0.0 ± 0.005 VDC. Save this
value by pressing the ENTER key.
To calibrate AC output, set the power source to the AC mode, high voltage
range. For MX units with the –HV optional range, use the 300V range for all
calibrations. Select the OUTPUT CAL entry from the MENU 3 screen. Refer to
section 4.2.14 for relevant LCD screen.
300 VAC Range Full-scale: Before programming the output voltage, first set the
ALC mode to OFF in the UTILITY, VOLT/CURR
CONTROL screen. Then select the 300 VAC Range from
the Program 1 screen. Program the output to 240.0
volts and 60 Hz and close the output relay. Go to the
OUTPUT CAL screen, select the VOLT FS, and enter
20000. With the shuttle, adjust this value to obtain
240 ± 0.05 volts at the output as measured with an
external DMM. Save this value by pressing the
ENTER key.
6.4.2 Output Cal 150 V AC Range (Series I only)
To calibrate AC output, set the power source to the AC mode, low voltage
range. Select the OUTPUT CAL entry from the MENU 3 screen. Refer to section
4.2.14 for relevant LCD screen. For Series II MX units, proceed to section 6.4.3
as there is only one calibration range.
To Next Page
