Ametek MX Series User Manual

User Manual – Rev BE AMETEK Programmable Power
MX Series 249
Seq #
CI P / N
Description
Ve n d o r
Qt y
Assy. Number and
Lo c a t i o n
Top Assembly 7003-400-01
F1 270246
FUSE, 200A, 600V
Ferraz Shawmut A6T200
Li t t l e f u s e J LLS 2 0 0
1
F2 270246
FUSE, 200A, 600V
Ferraz Shawmut A6T200
Li t t l e f u s e J LLS 2 0 0
1 For 208V / 230V Input
F3 270246
FUSE, 200A, 600V
Ferraz Shawmut A6T200
Li t t l e f u s e J LLS 2 0 0
1
F1 270226
FUSE, 110A, 600V
Ferraz Shawmut A6T110
Li t t l e f u s e J LLS 1 1 0
1
F2 270226
FUSE, 110A, 600V
Ferraz Shawmut A6T110
Li t t l e f u s e J LLS 1 1 0
1 For 400V / 480V Input
F3 270226
FUSE, 110A, 600V
Ferraz Shawmut A6T110
Li t t l e f u s e J LLS 1 1 0
1
Top Assembly 7003-400
F1 270246
FUSE, 200A, 600V Li t t l e f u s e J LLS 2 0 0 X
1
F2 270246
FUSE, 200A, 600V Li t t l e f u s e J LLS 2 0 0 X
1 For 208V / 230V Input
F3 270246
FUSE, 200A, 600V Li t t l e f u s e J LLS 2 0 0 X
1
F1 270226
FUSE, 110A, 600V Li t t l e f u s e J LLS1 0 0 X
1
F2 270226
FUSE, 110A, 600V Li t t l e f u s e J LLS1 0 0 X
1
For 380V / 400V / 480V
Input
F3 270226
FUSE, 110A, 600V Li t t l e f u s e J LLS1 0 0 X
1
Am p l i f i e r As s y. 1 5 k VA - 5440224-01
F1 270249
FUSE, 100A, 500V Ferraz Shawmut A50QS100-4
3 A7 , A8 , A9
F1-F32 858-KTK-15
FUSE,15A,600VAC/500VDC,FASTACT BUSSMANN KTK-15
32 A7 -A1 4
F1-F32 858-KTK-15
FUSE,15A,600VAC/500VDC,FASTACT BUSSMANN KTK-15
32 A8 -A1 4
F1-F32 858-KTK-15
FUSE,15A,600VAC/500VDC,FASTACT BUSSMANN KTK-15
32 A9 -A1 4
Amplifier Assy. 15kVA 7003-418-1 / 7003-425-1 / 7003-433-2
F1 270249
FUSE, 100A, 500V Ferraz Shawmut A50QS100-4
3 A7 , A8 , A9
F1-F8 270168
FUSE, 30A, 600V
Bussmann KTK-30
Li t t l e f u s e KLK-30
24
A7 , A8 , A9
7003-713-1
Low Voltage Power Supply 7003-722-1
F1 270192
FUSE, Poly switch Ra ych em RUE2 5 0
1 A6
F2 270192
FUSE, Poly switch Ra ych em RUE2 5 0
1 A6
F3 270189
FUSE, Poly switch Ra ych em RXEF110
1 A6
Low Voltage Power Supply 7003-702-1
F1 270192
FUSE, Poly switch
Ra ych e m RUE250
Ra ych e m RUEF25 0
1 A6
F2 270192
FUSE, P o l y s wit c h
Ra ych e m RUE250
Ra ych e m RUEF25 0
1 A6
Fan Control 7003-708-1
F1 858-125-00
FUSE, 5A, 125V Bussmann P CD-5-R
1 A7 -A8
F1 858-125-00
FUSE, 5A, 125V Bussmann PCD-5-R
1 A8 -A8
F1 858-125-00
FUSE, 5A, 125V Bussmann PCD-5-R
1 A9 -A8
F2 270192
FUSE, Poly switch
Ra ych e m RUE250
Ra ych e m RUEF25 0
1 A7 -A8
