User Manual – Rev BE AMETEK Programmable Power
MX Series 279
Generic tests files are distributed with the Virtual Panels program for both
editions of the test standard. Files applicable to Edition 2.0 have ED20 in their
file name. Do not mix these files, as the data setup will not be correct if you do.
To load a test file, select the Mode (Dips or Vars) and test standard revision
first, then use the File, Open menu to load the test parameters. Test parameters
can be a function of the EUT class. The different files provided with the program
cover the various EUT classes. The relevant EUT class 1, 2, 3 or X is listed in the
file names.
The user must select the desired test type before executing the test. Since both
test types require several test parameters, the test sequence parameters must
be entered in the data entry grid or loaded from disk using the File, Open menu
entry.
For complete details on how to use the Virtual Panels –411 option test screen,
refer to the on-line help of the Virtual Panels program available from the Help
menu.
