5-7
Component Identification Operator Manual 129390199
The AMSCO
®
Evolution
®
Series Steam Sterilizer control can be
programmed to retain values for up to 12 separate cycles. The eight
cycles shown on two cycle select screens, are the factory default
cycles. Up to four additional cycles can be programmed and
displayed on a third cycle select screen. If cycle parameters
different than those in Tables 6-1 and 6-2 are required, it is the
responsibility of the healthcare facility to consult and follow the
device manufacturer’s written instructions.
Warm Up Cycle, Dart Test (Bowie-Dick test) and Leak Test
parameters are fixed; the buttons for these cycles do not display
values for exposure temperature, exposure time or drying time.
5.7.1 Change Values Control
Screens
The values buttons are accessed through the cycle select screen by
pressing the options button (refer to Figure 5-9). These pads are
used for changing the operating values used in cycles, changing the
cycles displayed on the cycle selection menus and for changing the
operating settings of the sterilizer. Instructions for changing sterilizer
cycle parameters are in S
ECTION 7, CYCLE AND CONTROL VALUE
PROGRAMMING of this manual.
Figure 5-9. Options Screen
Figure 5-10. Change Cycle Values – Cycles Screen
Press Return Button to Return
to Select Cycle Screen
Press This Button To Access
Change Values Function
Press Individual Cycle Buttons
to Change Values for the Cycle.
Refer to SECTION 7.3. CHANGE
C
YCLE VALUES, PAGE 7-5 for
more information
