3-1
Installation Verification Operator Manual 129390199
3.1 Installation
Checklist
An Equipment Drawing showing all utility and space requirements was
supplied with the sterilizer. Clearance space shown on the drawing is
necessary for ease of installation and to assure proper operation and
maintenance of equipment. Uncrating and Installation Instructions
were also furnished with the sterilizer. If any of these documents are
missing or misplaced, contact STERIS giving the serial and model
numbers of the equipment. Replacement copies will be sent to you
promptly.
After installing this unit according to the instructions provided,
complete the following checklist to assure that your installation is
complete and correct. Or, if you desire, contact STERIS for a
technician to be scheduled to test your installation and demonstrate
proper equipment operation.
3.1.1 Service Clearance ❑ Clearance as specified on the equipment drawing must be
available.
3.1.2 Plumbing Services Feed Water:*
❑ Supply line shutoffs, with provisions for lockout/tagout, located
near the equipment.
❑ Backflow prevention (if required) is not provided by STERIS.
❑ Water Pressure 20 to 50 psig [1.4 to 3.5 bar], dynamic. Water
pressure supplied must be within specifications as shown on the
Equipment Drawing. If pressure is too high, a regulator must be
installed. If water pressure is too low, equipment performance will
be affected.
❑ Water Quality supplied must be within specifications. Improper
water quality adversely affects equipment operation. Damage to
the equipment due to improper water quality is not covered under
warranty.
❑ Drain Piping must be sloped properly, and sized to handle the
maximum waste flow from the sterilizer.
❑ STERILIZERS WITH AN ELECTRIC STEAM GENERATOR –
Generator Feedwater: 20-50 psig [1.4 to 3.5 bar], dynamic,
Recommended water temperature: 70-140°F (21-60°C)
Steam Supply:*
❑ Supply line shutoffs, with provisions for lockout/tagout, located
near the equipment.
❑ Supply piping adequately sized.
❑ Supply pressure 50 to 80 psig [3.5 to 5.5 bar], dynamic.
Steam Quality supplied must be within specifications.
❑ Steam Quality supplied is within specifications as found in the
General Notes.*
*Specifications can be found in the General Notes supplied with sterilizer documentation.
INSTALLATION VERIFICATION
3
