Syntax: [ IF cond ] AR = xop AND yop ;
AF OR constant
XOR
Permissible xops Permissible yops Permissible conds (see Table 15.9)
AX0 MR2 AY0 EQ LE AC
AX1 MR1 AY1 NE NEG NOT AC
AR MR0 AF GT POS MV
SR1 GE AV NOT MV
SR0 LT NOT AV NOT CE
Permissible constants (ADSP-217x, ADSP-218x, ADSP-21msp58/59 only)
0, 1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1024, 2048, 4096, 8192, 16384, 32767
–2, –3, –5, –9, –17, –33, –65, –129, –257, –513, –1025, –2049, –4097, –8193, –16385, –
32768
Example: AR = AX0 XOR AY0;
IF FLAG_IN AR = MR0 AND 8192;
Description: Test the optional condition and if true, then perform the
specified bitwise logical operation (logical AND, inclusive OR, or exclusive
OR). If the condition is not true then perform a no-operation. Omitting the
condition performs the logical operation unconditionally. The operands are
contained in the data registers or constant specified in the instruction.
The xop
AND/OR/XOR constant operation is only available on the ADSP-217x,
ADSP-218x, and ADSP-21msp58/59 processors and may not be used in
multifunction instructions.
Status Generated:
ASTAT: 7 6 543210
SS MV AQ AS AC AV AN AZ
–– – – 0 0* *
AZ Set if the result equals zero. Cleared otherwise.
AN Set if the result is negative. Cleared otherwise.
AV Always cleared.
AC Always cleared.
ALU
AND, OR, XOR
(instruction continues on next page)
