Program Control3
3 – 20
3.5 STATUS REGISTERS & STATUS STACK
Processor status and mode bits are maintained in internal registers which
can be independently read and written over the DMD bus. These registers
are:
ASTAT Arithmetic status register
SSTAT Stack status register(read-only)
MSTAT Mode status register
ICNTL Interrupt control register
IMASK Interrupt mask register
IFC Interrupt force/clear register(write-only)
The interrupt-configuring status registers are described in the previous
section. ASTAT, SSTAT, and MSTAT are discussed in the following
sections.
The current ASTAT, MSTAT, and IMASK values are pushed onto the
status stack when the processor responds to an interrupt; they are popped
upon return from the interrupt service routine (with the RTI instruction).
The depth of the stack varies from processor to processor. In each case,
sufficient stack depth is provided to accommodate nesting of all
interrupts.
3.5.1 Arithmetic Status Register (ASTAT)
ASTAT is eight bits wide and holds the status information generated by
the computational blocks of the processor. The individual bits of ASTAT
are defined as shown in Figure 3.4. The bits which express a particular
condition (AZ, AN, AV, AC, MV) are all positive sense (1=true, 0=false).
543210
000000
76
00
ALU Result Zero
ALU Carry
ALU X Input Sign
ALU Result Negative
ALU Overflow
SS ASMV AQ AC ANAV AZ
ALU Quotient
MAC Overflow
Shifter Input Sign
Figure 3.4 ASTAT Register
