10.3 DATA MEMORY INTERFACE
This section describes the data memory interface of all ADSP-21xx
processors except the ADSP-2181.
The processors supply a 14-bit address on the data memory address bus
(DMA) which is multiplexed off-chip. Data is transferred across the upper
16 bits of the 24-bit memory data bus, which is also multiplexed off-chip.
A data memory select pin,
DMS
, indicates that the address bus is being
driven with a data memory address and memory can be selected.
Two control lines indicate the direction of the transfer. Memory read (
RD
)
is active low signaling a read and memory write (
WR
) is active low for a
write operation. Typically, you would connect
DMS
to
CE
(Chip Enable),
RD
to
OE
(Output Enable) and
WR
to
WE
(Write Enable) of your memory.
10.3.1 External Data Memory Read/Write
Internal data memory accesses are transparent to the external memory
interface. Only off-chip accesses drive the memory interface. Off-chip data
memory accesses follow the same sequence as off-chip program memory
accesses, namely:
1. The processor places the address on the DMA bus, which is
multiplexed off-chip, and
DMS
is asserted.
2.
RD
or
WR
is asserted.
3. Within a specified time, data is placed on the data bus, multiplexed to
the internal DMD bus.
4. The data is read or written and
RD
(or
WR
) is deasserted.
5.
DMS
is deasserted.
The basic read and write cycles are illustrated in Figure 10.2.
For a dual off-chip data fetch, the data from program memory is read first,
then the data memory data.
