4-49
7. <Service Option>
This specifies the loop-back mode of the mobile station.
Set SO2 (Service option 2) or SO9 (Service option 9) for carrying out the
measurement.
When SO1 (Service option 1) or SO3 (Service option 3) is set, normal voice
communication state comes on.
In this case, the MT8801C returns the voice from mobile station after
approx. 1 sec. delay. Note that this parameter can be set at all Call Process-
ing states.
The Service Option enabled to be set is determined by the setting of the
Using Specification, as shown in the following table.
Using specification Service option
IS-95A
TSB74
J-STD-008
ARIB-T53
KOREA-PCS
SO1, SO2, SO9
SO1, SO2, SO9
SO1, SO2, SO9
SO2, SO3, SO9
SO1, SO2, SO9
8. <Traffic Channel Data Rate>
This sets the data rate of the Traffic channel.
The data rate is shown below, depending on the Rate Set.
Rate set 2
(Service option 9)
Full
1/2
1/4
1/8
14400 bps
7200 bps
3600 bps
1800 bps
Rate set 1
(Service option 2)
9600 bps
4800 bps
2400 bps
1200 bps
9. <MS Power Level>
This specifies the output level of the mobile station (MS) in Analog mode.
The output level depends on the output level class of the mobile station, as
shown in the table below:
Output level from MS [dBm]
MS Power Level
Output level from MS [dBm]
MS output level class
I II III
0
1
2 (Initial value)
3
4
5
6
7
36 32 28
32 32 28
28 28 28
24 24 24
20 20 20
16 16 16
12 12 12
88 8
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
