Section 4 Operation
4-82
(7) Access Probe output power measurement: Access Probe Measure
screen
• The Access Probe Measure screen appears by the following operation:
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Func on to display the Main Menu at the bottom of the screen.
2. [TX&RX Tester] F1 Sets TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. [TX Measure] F1 Displays the first page of the TX Measure menu.
4. Next Menu [ ] Displays the second page of the Main Func menu.
5. [Start] F5 Sets Call Processing state to Idle.
6. [Access Probe Measure] F8 Displays the Access Probe Measure screen.
1
MT8801 99/12/31 12:00:00
<< Access Probe Measure (CDMA) >>
Access Probe
->
*
Back
Screen
Start/Stop
Calibration
M
U
1
2
Channel : 0000CH Frequency : 1000.000 000MHz Level : -10dBm
BS Output
Level
Main Func
On Off
#
###
#
1
2
Access Probe
->
Back
Screen
BS Output
Level Cal.
Measure State : Stop
Measured Level of Access Probes (-- bursts / 999 Frames)
AP Frame Level AP Frame Level AP Frame Level
1 -------------- 18 -------------- 35 --------------
2 -------------- 19 -------------- 36 --------------
3 -------------- 20 -------------- 37 --------------
4 -------------- 21 -------------- 38 --------------
5 -------------- 22 -------------- 39 --------------
6 -------------- 23 -------------- 40 --------------
7 -------------- 24 -------------- 41 --------------
8 -------------- 25 -------------- 42 --------------
9 -------------- 26 -------------- 43 --------------
10 -------------- 27 -------------- 44 --------------
11 -------------- 28 -------------- 45 --------------
12 -------------- 29 -------------- 46 --------------
13 -------------- 30 -------------- 47 --------------
14 -------------- 31 -------------- 48 --------------
15 -------------- 32 -------------- 49 --------------
16 -------------- 33 -------------- 50 --------------
17 -------------- 34 --------------
1 2
Sync
Channel
Level
Paging
Channel
Level
Traffic
Channel
Level
Pilot
Channel
Level
Fig. 4-11 (1/3) Access Probe Measure Screen
