Section 4 Operation
4-84
The 2nd page of the main function keys on the Access Probe Measure screen
1
Reference
Level
Main Func
On Off
#
2
• Function keys:
Main function key:
1st page
[BS Output Level] F1: Sets the level of output from the MT8801C.
Initial value: –55.0 dBm
Setting range:–133.0 dBm to –18.0 dBm (RF Output: Main, AWGN Off)
–133.0 dBm to +2.0 dBm (RF Output: AUX, AWGN Off)
–133.0 dBm to –24.0 dBm (RF Output: Main, AWGN On)
–133.0 dBm to –4.0 dBm (RF Output: AUX, AWGN On)
Resolution: 0.1 dB
[Pilot Channel Level] F2: Sets the level of Pilot Channel output from the MT8801C.
Initial value: –7.0 dB
Setting range:–5.0 dB to –10.0 dB, 0 dB
Setting 0 dB at Pilot Channel can be performed only by GPIB
command. (See para. 2.5.8 of Remote Control volume of this
manual.)
Resolution: 0.1 dB
[Sync Channel Level] F3: Sets the level of Sync Channel output from the MT8801C.
Initial value: –16.0 dB
Setting range:–7.0 dB to –20.0 dB
Resolution: 0.1 dB
[Paging Channel Level] F4: Sets the level of Paging Channel output from the MT8801C.
Initial value: –12.0 dB
Setting range:–7.0 dB to –20.0 dB (Paging Data Rate: “Full”)
Resolution: 0.1 dB
[Traffic Channel Level] F5: Sets the level of Traffic Channel output from the MT8801C.
Initial value: –16.0 dB
Setting range:–7.0 dB to –20.0 dB (Data Rate: “Full”)
–10.0 dB to –23.0 dB (Data Rate: “1/2”)
–13.0 dB to –26.0 dB (Data Rate: “1/4”)
–16.0 dB to –29.0 dB (Data Rate: “1/8”)
Resolution: 0.1 dB
