Section 4 Operation
4-100
(11) Spurious measurement: Spurious Emission screen, Setup Fre-
quency Table screen
Measures the specified spurious emission of the signal from the transmitter ac-
cording to the specified parameter in the Setup Common Parameter Screen
(paragraph 4.3.5).
Sets a table of measuring spurious frequency (Setup Frequency Table Screen),
and 100 different table saving (Save Frequency Table Screen) and recalling (Re-
call Frequency Table Screen) can be done in the FD (3.5-inch floppy disk).
(a) Spurious measurement: Spurious Emission Screen
• Display the Spurious Emission Screen in the following operation.
Step Key operation Description
1. [Main Func on off] F6 Turns on the Main Func, and displays the main menu at the bottom of the
screen.
2. [TX & RX Tester] F1 Switches to the TX Tester mode.
Displays the Setup Common Parameter Screen.
3. [TX Measure] F1 Displays the first page of the TX Measure menu.
4. Next Menu [ ] Displays the second page of the TX Measure menu.
5. [Spurious Emission] F12 Displays the Spurious Emission Screen.
Main Func
1
Spurious
MT8801 99-04-30 12:00:00
<< Spurious Emittion (CDMA) >>
Channel
#
Level
#
->
Back
Screen
*
*
Spurious
Mode
Unit
Range
Adjust
Calibration
*
Channel : 1092CH Frequency : 887.650 000MHz Level : -10dBm
C
U
M
Spurious : Spot
Frequency Table : Not Named RBW:3kHz RBW:30kHz RBW:1MHz
f 1= 825.030 000 MHz : -65.00 dB -55.00 dB -40.00 dB
f 2= 1 650.060 000 MHz : -70.00 dB -60.00 dB -55.00 dB
f 3= 2 475.090 000 MHz : -75.00 dB -65.00 dB -60.00 dB
f 4= - ---.--- --- MHz :
f 5= - ---.--- --- MHz :
f 6= - ---.--- --- MHz :
f 7= - ---.--- --- MHz :
f 8= - ---.--- --- MHz :
f 9= - ---.--- --- MHz :
f10= - ---.--- --- MHz :
f11= - ---.--- --- MHz :
f12= - ---.--- --- MHz :
f13= - ---.--- --- MHz :
f14= - ---.--- --- MHz :
f15= - ---.--- --- MHz :
1
1
Main Func
1
Spurious
->
Back
Screen
*
Recall
Frequency
Table
Setup
Frequency
Table
1
1
->
2
On OffOn Off
Fig. 4-17 Spurious Emission Screen
