4-103
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
• Items to be set in the Setup Frequency Table Screen are listed below.
Item Range Resolution Initial value
Frequency
f 1 100 Hz to 3 GHz 1 Hz 1775.300000 MHz
f 2 100 Hz to 3 GHz 1 Hz 2662.950000 MHz
f 3 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f 4 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f 5 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f 6 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f 7 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f 8 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f 9 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f10 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f11 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f12 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f13 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f14 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
f15 100 Hz to 3 GHz 1 Hz ——.——— MHz (Undefined)
• Function key
Main function key: None
Function key:
1st page
[Save Frequency Table] F7: Displays the menu for saving frequency table. (See paragraph 4.3.8)
[Delete] F8: Deletes the frequency at cursor position, and scrolls up by one line all frequencies
below.
[Insert] F9: Scrolls down by one line all frequencies below cursor and makes one space line for
input of frequency data.
[Harmonics] F10: Sets f1, f2, and f3--- to 2, 3, and 4--- times frequency of the Setup Common Parameter
Screen. However, frequencies over 3 GHz are not set.
[Clear] F11: Deletes all the displayed frequencies.
[Back Screen] F12: Displays the previous screen.
2nd page
[Recall Frequency Table] F7: Displays the menu for frequency table recall. (See paragraph 4.3.11)
[Back Screen] F12: Displays the previous screen.
