Section 4 Operation
4-108
(2) Signal generator + analog transmitter measurement: Analog TX
Meas with SG screen
On the Analog TX Meas with SG screen, output an RF signal from the
MT8801B and measure the RF signal from the DUT.
AF Osc.2 signal can also be output to the AF output terminal as required.
Switch to the Analog TX Meas with SG screen according to the following steps:
Step Key operation Description
1. [Main Func on off] F6 Sets Main Func on to display the first page of the Main Menu at the bottom of
the screen.
2. [TX&RX Tester] F1 Sets the TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. Cursor [ ][ ][ ][ ] Move the cursor to Control Band.
[Set] [ ][ ] [Set] Select A800 MHz and press the [Set] key to validate it.
4. Next Menu [ ] Displays the second page of the Main Func menu.
5. [Start] F5 Call Proc. State becomes Idle state.
6. Power On Turns the power of the MS to on. Wait until the MS is registrated and the Call
Proc. State becomes Idle (Regist).
7. [NW Originate] F2 Call Proc. State becomes Conversation.
8. [TX Measure] F1 Displays the first page of the TX Measure menu.
9. [Analog TX Meas with SG] F10
Displays the Analog TX Meas with SG screen.
1 2
2
Main Func
On Off
1
MT8801 99-12-31 12:00:00 Measure : Continuous
<<Analog TX Meas with SG (CDMA)>> Storage : Normal
AF Level TX RF
Level/Power
AF Level
*
Distortion
Unit
Set
relative
*
Filter
*
HPF
*
De-emphasis
->
Back
Screen
RF Frequency/Power
8. 000kHz
Det : (p-p)/2
HPF : 300Hz LPF : 3kHz
Deviation FM
AF Level/Distortion
TX RF
Frequency
Deviation Modulation
M
C
U
RX Frequency RX Level
870.030000 MHz —55.0dBm
( 1CH)
AF Osc.1 (Mod:SAT)
SAT1 5970.0Hz Deviation 2.00kHz
AF Osc.2 (AF)
Freq. 1004.0Hz Level 1.000V
External (Mod)
Deviation 8.00kHz
Channel : 1CH Frequency : 825.030000MHz Level : 30dBm
825.030000MHz
+000.000kHz
30.0dBm(1.000W)
10.0
dB Relative
Range : 30.0dBm
Level
5.6569kHz
rms
— 50.00dB
Relative
Distortion
0.32
%
Frequency
1004.00Hz
Filter : ITU-T P.53
HPE : 400Hz
Fig. 4-20 Analog TX Meas with SG screen
To Next Page
