Anritsu MT8801C - Page 175

Section 4 Operation
4-120
(2) Setting signal: Setup Signal screen
Sets the Forward signal at Signal Setup screen.
• The Signal Setup screen appears by the following operation:
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Func on to display the Main Menu at the bottom of the screen.
2. [TX&RX Tester] F1 Sets TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. [RX Measure] F2 Displays the first page of the RX Measure menu.
4. Next Menu [ ] Displays the second page of the RX Measure menu.
5. [Setup Signal] F10 Displays the Setup Signal screen.
1
Main Func
On Off
1
->
Back
Screen
Setup Signal
MT8801 99-12-31 12:00:00
<< Setup Signal (CDMA) >>
Channel Level
Pilot Channel Level : [- 7.0dB]
Synch Channel Level : [-16.0dB]
Paging Channel Level : [-12.0dB]
Traffic Channel Level : [-16.0dB]
OCNS Channel Level : (-1.6dB)
Baseband
CDMA Reference Output : (19.6608MHz)
CDMA Reference Input : [Int]
Fig. 4-22 Setup Signal Screen
