4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
Item Range Resolution Initial value
Channel Level Note 1
Pilot Channel Level –5.0 dB to –10.0 dB 0.1 dB –7.0 dB
Sync Channel Level –7.0 dB to –20.0 dB 0.1 dB –16.0 dB
Paging Channel Level –7.0 dB to –20.0 dB 0.1 dB –12.0 dB
Traffic Channel Level –7.0 dB to –20.0 dB (Data Rate: “Full”) 0.1 dB –16.0 dB
–10.0 dB to –23.0 dB (Data Rate: “1/2”)
–13.0 dB to –26.0 dB (Data Rate: “1/4”)
–16.0 dB to –29.0 dB (Data Rate: “1/8”)
Baseband
CDMA Reference Output 19.6608 MHz (None) 19.6608 MHz Note 2
CDMA Reference Input Int (None) Int
Notes:
1. <Channel Level>
Channel Level sets the each level of the Pilot, Sync, Paging, and Traffic
channels.
Each the set value is the average power per PN chip with the relative value
to the total power of the Forward channel.
The average power per bit is the same at –16.0 dB of Data rate ‘Full’ and –
19.0 dB of Data rate ‘1/2’.
2. <CDMA Reference Output>
Outputs the Baseband Clock of the selected frequency from the CDMA
Reference Output connector.
• Function key:
Main function key (None)
Function key
[Back screen] F12: Displays the previous screen.
