4-127
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
4.3.9 Analog receiver measurement
Set Control Band to A800MHz on the Setup Common Parameter screen, then press
the [RX Measure] F2 main function key to set analog receiver measurement mode.
This paragraph describes how to set parameters (on the Setup Analog RX Measure
Parameter screen) and how to measure the analog receiver (on the Analog RX Mea-
sure screen) for analog receiver measurement.
(1) Setting the parameters: Setup Analog RX Measure Parameter
screen
The following describes how to set parameters (on the Setup Analog RX Mea-
sure Parameter screen) for analog receiver measurement.
Display the Setup Analog RX Measure Parameter screen according to the fol-
lowing steps, then set the RX parameters.
Step key operation Description
1. [Main Func on off] F6 Sets the Main Func on to display the first page of the Main Menu at the
bottom of the screen.
2. [TX&RX Tester] F1 Sets TX&RX Tester mode.
The Setup Common Parameter screen appears.
3. Cursor [ ][ ][ ][ ] Move the cursor to Control Band.
[Set] [ ][ ] [Set] Select A800 MHz and press the [Set] key to validate it.
4. [RX Measure] F2 Displays the first page of the RX Measure menu.
5. Next Menu [ ] Displays the second page of the RX Measure menu.
6. [Setup Analog RX Parameter] F9
Displays the Setup Analog RX Measure Parameter screen.
