4-145
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
• Recalling parameters and data
This paragraph describes how to recall measurement parameters from the floppy disk.
Step Key operation Description
A When the [Recall] F5 main function key is used:
1. Insert a recall floppy disk (FD) into the FD driver at the bottom left of the
MT8801C.
2. [Main Func on off] F6 Sets Main Func to on. Displays Main Menu on the main function keys.
3. [Recall] F4 Changes to Recall Parameter mode. Displays the Recall function keys in F7
to F12, and moves to the Recall screen for parameter and data.
Searches the FD for parameter and data files, and displays them on the screen.
4. Proceed to Step 5 below.
B When [Recall Template] F7 function key of Gated Power Measure screen is used
1. Insert a recall FD into the FD driver at the bottom left of the MT8801C.
2. [Recall Template] F7 Changes to the Recall Template screen. Displays the Recall function keys in
F7 to F12, then moves to the Recall screen for parameter and data.
3. Searches the FD for parameter and data files, and displays them on the screen.
4. Proceed to Step 5 below.
C When the [Recall Pattern] F7 function key of Setup RX Measure Parameter screen is used
1. Insert a recall floppy disk (FD) into the FD driver at the bottom left of the
MT8801C.
2. [Recall Pattern] F7 Changes to the Recall Pattern screen. Displays the recall function keys in F7
to F12, then moves to the Recall screen for parameter and data.
3. Searches the FD for parameter and data files, and displays them on the screen.
4. Proceed to Step 5 below.
(Under state where the Recall menu is displayed)
5. [Display Dir./Next Page] F8 Displays the directory containing the file to be recalled. Check the file to be
recalled.
6. Cursor [ ] [ ] Select the file to be recalled.
7. [File No.] F9 Sets the number of any file to be recalled.
(The file to be recalled can be specified by the file number, too.)
8. [Set] Confirms the file to be recalled. The MT8801C reads the specified file.
Then, returns to the previous screen automatically.
