1-9
Table 1-7 MT8801C Option 12 : CDMA Measurement Specifications (continued)
Signal generator
FER measurement
Reception
measurement
Call processing function
Frequency range
Level range
Relative level accuracy
Waveform quality
Channel level
Channel level accuracy
AWGN level range
AWGN level accuracy
Auxilliary output signal
Function
Measurement result
Function
Protocol
Input frequency range
869.01 MHz to 893.97 MHz, 30 kHz step (IS-95A, TSB74)
1930.00 MHz to 1989.95 MHz, 50 kHz step (J-STD-008)
832.0125 MHz to 833.9875 MHz, 843.0125 MHz to 845.9875 MHz,
860.0125 MHz to 869.9875 MHz, 12.5 kHz step (ARIB STD-T53)
1805.05 MHz to 1870.00 MHz, 50 kHz step (KOREA-PCS)
–18 to –133 dBm (Main, AWGN off)
+2 to –133 dBm (AUX, AWGN off)
–24 to –133 dBm (Main, AWGN on)
–4 to –133 dBm (AUX, AWGN on)
At varying level on open-loop power-control time-response measurement
±0.2 dB/20 dB (18 to 28°C)
ρ>0.99 (Pilot Channel 0 dB)
Pilot Channel 0 dB, –5 to –10 dB, 0.1 dB step
Paging Channel –7 to –20 dB, 0.1 dB step
Sync Channel –7 to –20 dB, 0.1 dB step
Traffic Channel –7 to –20 dB, 0.1 dB step (full rate)
–10 to –23 dB, 0.1 dB step (half rate)
–13 to –26dB, 0.1dB step (quarter rate)
–16 to –29dB, 0.1dB step (eighth rate)
OCNS Channel Automatic setting
±0.2 dB (relative level accuracy between any two channels)
+6 to –20 dB/1.23 MHz or off, 0.1 dB step
(Relative level to 1.23 MHz bandwidth power of BS transmission signal)
±0.2 dB (Relative level to Forward Traffic Channel power)
CDMA Reference output
19.6608 MHz, BNC connector, TTL level
CDMA Timing output
1.25 ms, 20 ms, 26.67 ms, 80 ms, 2 s, D-SUB 25 pins, TTL level
Measures frame error rate of traffic channel using mobile station loop-back mode
FER measurement, number of error frames, number of test frames reliability limit
Pass/Fail
Executes processing of registration, origination, termination, conversation,
loop back (service option 2), frequency channel change,
mobile station disconnect, network disconnect, CDMA-to-Analog handoff (IS-95A,
TSB74, J-STD-008)
IS-95A, TSB74, J-STD-008 (CDMA, Analog), ARIB STD-T53
824.01 MHz to 848.97 MHz, 30 kHz step (IS-95A, TSB74)
1850.00 MHz to 1909.95 MHz, 50 kHz step (J-STD-008)
887.0125 MHz to 888.9875 MHz, 898.0125 MHz to 900.9875 MHz,
915.0125 MHz to 924.9875 MHz, 12.5 kHz step (ARIB STD-T53)
1715.05 MHz to 1780.00 MHz, 50kHz step (KOREA-PCS)
1.5 Specifications
