4-29
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
Step Key operation Description
1. Cursor [ ] [ ] Moves the cursor to the Title entry area.
2. [Set] Opens the Tile entry window.
3. Step [ ] [ ] Moves the cursor into position in the Title entry area to enter character.
4. Cursor [<] [>] Select a character.
5. [Enter] Defines the character.
6. [BS] Correct any incorrect character.
7. Repeat steps 3 to 6 to enter all characters in the Title entry area.
8. [Set] Defines the entered character string.
• Function keys
Main function key: None
Function keys:
[Date] F7: Opens the date entry window.
[Time] F8: Opens the time entry window.
[Power On Initial] F9: Displays the Power On menu to select Initialization modes, which are classified into
Previous Status and Recall File.
Initial value: Previous Status
When Previous Status mode is selected, the parameters after power-on retain the sta-
tus held before the previous power-off.
When Recall File mode is selected, the parameters after power-on are set by reading
the specified file.
[Previous Status] F7 Sets the parameters after power-on to the status held before the previous
power-off.
[Recall File] F8 Sets the mode in that the parameters after power-on are read from floppy disk.
[File No.] F9 Opens the parameter-file setting-location (number) entry window.
File No.: 0 to 99, Initial value: 0
[return] F12 Returns to the previous menu.
To Next Page
