AOR AR5001D - 5-3-5 RECORDING AUDIO; 5-3-6 PLAYBACK AUDIO; 5-3-7 DELETE FILES

17
3 – IF BW
Figure THREE for the numeric input of frequencies, bank, channel numbers, etc.
Press the [FUNC] key, and press the [3] key to activate the IF bandwidth menu. In normal operation,
“AUTO” will be displayed on the LCD and the IF bandwidth will be automatically selected according to the
ba nd plan. To change the bandwidth manually, rotate the sub dial to select the desired bandwidth. To
accept the new bandwidth, press the [MHz] key.
4 – S. SCAN
Figure FOUR for the numeric input of frequencies, bank, channel numbers, etc.
Press the [FUNC] key, and press the [4] key to activate SELECT SCAN. Select scan enables you to ‘tag’
memory channels to make a temporary list of up to 100 channels in the same memory bank for scanning
in a separate list called SELECT SCAN LIST.
5 – 2F. OFFSET
Figure FIVE for the numeric input of frequencies, bank, channe l numbers, etc.
Press the [FUNC] key, and press the [5] key for two seconds to activate/deactivate the dual frequency
receive function in offset mode.
6 - RF. GAIN
Figure SIX for the numeric input of frequencies, bank, channel numbers, etc.
Press the [FUNC] key, and press the [6] key to activate the manual RF gain control. To change the RF
ga in manually, rotate the squelch knob. To cancel the manual RF gain control, repeat the above steps.
Note: The manual RF gain control is not available while the receiver is in AGC mode.
7 - CLOCK
Figure SEVEN for the numeric input of frequencies, bank, channel numbers, etc.
Press the [FUNC] key, and press the [7] key to display the current time.
Rotating the sub dial allows you to selec t between the two clocks.
To set the clock, press the [FUNC] key and then press and hold the [7] key for two seconds.
On the screen, you can select 12H/24H, set the date and time using the sub dial.
Press the [MHz] key to confirm entry.
