View data in the Array Viewer
Use the Array Viewer during or after a run to examine the quality of data from all
capillaries. You can view all the capillaries (vertical axis) as a function of time/data
point (horizontal axis).
In the navigation pane of the Data Collection Software, select GA Instruments4
ga37304 Instrument name4 Array Viewer.
1
2
1
Capillary 1
2
Capillary 48 or 96
How to zoom
1.
T
o expand the view, click-drag the mouse over the area of interest.
2.
Click
to return to full view.
Display or hide c
olor
Click individual colors in the color bar to view or hide the color in the Array View.
Chapter 5 Run the ins
trument
View data from the run
5
70
3730xl DNA Analyzer with 3730xl Data Collection Software 5 User Guide
