Applied Biosystems 3730xl User Manual

• Holes of the plate retainer and the septa strip are aligned
1
1
Plate retainer holes and septa holes are not alignted
10.
Dry the exterior of the reserv
oirs using lint-free wipes.
Place reservoirs into the instrument
1.
Connect the Buer reservoir plate base cable into the heater outlet inside the
instrument.
1
2
1
Heater outlet
2
Plate base cable
2.
Mov
e the cable out of the way of the autosampler. Move the buer reservoir to
the Buer position (left).
1
32
1
Buffer reservoir
2
Left reservoir position
3
Middle reservoir position
Chapter 2 Prepare the instrument
Place reservoirs into the instrument
2
32
3730xl DNA Analyzer with 3730xl Data Collection Software 5 User Guide
