Instrument specifications
Instrument specifications
Table 9 3730xl DNA Analyzer physical dimensions, weight, and power consumption
Component Height Length (depth) Width Weight
Instrument 90 cm (35.5 in.) 65 cm (26.0 in.) 100 cm (40.0 in.) with
door closed
170 cm (67.0 in.) with
door open
~186 kg (411 lbs)
Computer 36.0 cm (14.2 in.) 41.7 cm (16.4 in.) 17.5 cm (6.9 in.) ~12.2 kg (27 lbs)
Monitor (compressed) 36.9 cm (14.5 in.) 18.0 cm (7.1 in.) 40.6 cm (16.0 in.) ~5.0 kg (11.0 lbs)
Keyboard 3 cm (2 in.) 44.5 cm (6 in.) 14.0 cm (17.5 in.) 1 kg (0.2 lbs)
• Access to all four sides of the instrument is required for servicing.
•
Do not block access to the rear of the instrument.
• Minimum rear clearance is 30.5 cm (12 in.).
• If two instruments are placed back-to-back, allow 61 cm (24 in.) of clearance
between the instruments.
Table 10 Operating specifications
Component Specification
Laser
• Long-life, single-line 505 nm, solid-state laser
excitation source
• Laser Output power 20mW
• Beam divergence 1.4 mrad
LED
• Emitting color Natural White
• Luminous Intensity 250 Cd
Electrophoresis voltage Up to 20 kV
Oven temperature Active temperature control from 18°C to 70°C
B
142
3730xl DNA Analyzer with 3730xl Data Collection Software 5 User Guide
