SmartROC D65 T4F 10 Options
182 No: 713944459.6 en
Pos. Function Description
3+4 Saturation setting Press buttons 3 and 4 simultan-
eously in order to activate the
setting mode. Use the plus and
minus keys to select saturation.
5 Alternate/previous menu Go back to previous menu.
6 Minus Go to next menu option or move
to the left.
7 Plus Go to previous menu option or
move to the right.
8 Enter Change to Standby, select or
activate options in the menus.
Table28: Checks
Menus
n Open the Service menu by pressing the buttons (1), (6) and (7) simultaneously.
n Navigate with the buttons:
l (5) Alternate/previous menu Go back to previous menu
l (6) Minus Go to next menu
l (7) Plus Go to previous menu
l (8) Enter Select or activate the desired option
Menu Submenu Description
Camera settings Mirror Mirrors the image (left/right).
Up and down Turns the image up and down.
Brightness Adjusts brightness, can also be
done directly with button 4.
Contrast Adjusts contrast, can also be
done directly with button 3.
Saturation Adjusts saturation, can also be
done directly with buttons 3+4.
Change delay Not used
Horizontal line marking Shows a reference line on the
screen. Shown as horizontal
green line.
Line arrangement Adapts the vertical height of the
reference line (0 - 100).
Vertical line arrangement Shows a reference line on the
screen. Shown as vertical green
line.
