SmartROC D65 T4F 5 Controls
39 No: 713944459.6 en
6 Watermist system, max.
7 Watermist system, decrease of the water amount
in auto mode
8 Idling speed (1100 rpm)
9 Not activated
10 Tramming High Speed
11 Signal Horn
12 DCT ON/OFF
13 Not used
14 Reduced flushing air
15 Jack in (with a double press of the button the jack
automatically retracts all the way)
16 Full flushing air
17 Jack out
18 Not activated
19 Rev up diesel engine (between 1500-1800 rpm)
20 Rev down diesel engine (between 1500-1800
rpm)
21 Left track oscillation (forward)
22 Right Track Oscillation (Forward)
23 Left track oscillation (reverse)
24 Right track oscillation (reverse)
25 Track Oscillation Lock
35 Rod handling
36 Suction hood/Drill-steel support/Break table
