SmartROC D65 T4F 5 Controls
41 No: 713944459.6 en
c Upper drill-steel support (open)
d Suction hood - Down
e Suction hood - Up
Movement with depressed top
button
a Lower drill-steel support (closed)
b Neutral (lever in centre position)
c Lower drill-steel support (open)
d Not used
e Not used
36 Break table, button 3 not ac-
tivated
a Upper break table (Close)
b Neutral (lever in centre position)
c Upper break table (Open)
d Suction hood - Down
e Suction hood - Up
Movement with depressed top
button
a Lower break table (Close)
b Neutral (lever in centre position)
c Lower break table (Open)
d Not used
e Semi-automatic breaking
Table14: Levers for rod handling and suction hood.
