Installation: Task 3 — Installing the MAPD Assembly in
the Switch
Issue 3 May 2002
2-21
7. As the MAPD system comes up, watch the Liquid Crystal Display (LCD) on
the faceplate (see Figure 2-7). The LCD identifies the MAPD states and
alarms. When the MAPD system is coming up, the LCD should display
the following states (in order):
â– FWBOOT (firmware board tests)
â– PCBIOS (Pentium processor card diagnostics)
â– OSINIT (operating system initialization)
â– PGMFW (update MAPD FLASH PROMS, if necessary)
â– AINIT (MAPD System Initialization)
NOTE:
If the system does not come up to the AINIT state within 10
minutes (4 to 7 minutes is average), contact the Technical
Service Center (TSC) for assistance.
â– ASAI x (MAPD running with x established ASAI links)
