Page #182 background imageLoading...
Page #182 background image
AvL Proprietary and Confidential
Content is Subject to Change without Notice Page 182 of 195
0x000C
"Waiting"
"Waiting on modem to allow move."
0x000D
"Performing Move To"
"Moving to commanded position"
0x000E
"Moving to Home"
"Moving to Home Position"
0x000F
"Stowing"
"Stowing"
0x0010
"Compass Cal"
"Performing compass calibration."
0x0011
"X-Pol (H/V) moving"
"Cross Pol (H/V) moving Pol"
0x0012
"Initializing Sensors"
"Initializing El Encoder"
0x0013
"In Manual Control"
"In Manual Control and Jog mode"
0x0014
"Moving"
"Moving"
0x0015
"Coarse Peaking"
"Coarse Peaking"
0x0016
"Coarse Peaking done"
"Coarse Peaking Complete"
0x0017
"Fine Peaking"
"Fine Peaking"
0x0018
"Fine Peaking Done"
"Fine Peaking Complete"
0x0019
"Fine Peaking Pol"
"Fine Peaking POL"
0x001A
"Peaking"
"Peaking"
0x001B
"Idle"
"Idle"
0x001C
"Tracking for signal"
"Moving to maintain signal"
0x001D
"Position Hold Active"
"Moving to maintain signal"
0x001E
"Opening wings"
"Opening wings."
0x001F
"Closing wings"
"Closing wings."
0x0100
"Mount Reflector"
"Moving to reflector mount position"
0x0101
"Dismount reflector"
"Moving to reflector dismount position"
0x0102
"Acquire Complete"
"Locked and Acquired continuing pos/wind hold
and track ops"
0x0103
"Tilt Compensating"
"Calculating Tilt compensation"
0x0104
"Moving to Target"
"Moving to begin Scanning in Az for Target Sat
Signal"
0x0105
"Moving back to Peak "
"Moving back to Peak signal"
0x0106
"Calibration"
"Performing Calibration"
0x0107
"Initializing Sensors"
"Initializing Az Encoder"
0x0108
"Initializing Sensors"
"Initializing POL Encoder"
0x0109
"Intializing sensors"
"Intializing sensors"
0x0110
"Acquiring"
"Paused"
0x010A
"Waiting for signal"
"Acquiring, waiting for modem/beacon signal."
0x010B
"Wait. Cal Heading"
"Please wait. Calibrating heading."
0x010C
"Elevation Deploy"
"Moving in elevation to deploy range"
0x010D
"Elevation Stow"
"Moving in elevation to the stow position"
0x010E
"Wait. Cal Heading"
"Please wait. Calibrating heading."
0x010F
"Mod Cmd Running"
"Please wait. Module command running."
0x0111
"No Ref., Calibrating "
"Invalid Ref. Satellites, Calibrating Heading "
0x0112
"Adj. using Ref #1 "
"Adjusting Heading using Reference Sat. #1"
0x0113
"Adj. using Ref #2 "
"Adjusting Heading using Reference Sat. #2"
0x0114
"Ref 1 Fail use Ref 2 "
"Ref. Satellite #1 Failed, using Ref. Satellite #2"
0x0115
"Ref 2 Fail use Ref 1"
"Ref. Satellite #2 Failed, using Ref. Satellite #1"
