９‐１０
5. Press the G-key below the
icon to start downloading.
The following information screen will be shown during downloading.
A The name of the design and total stitch number
Width Width of the design
Height Height length of the design
Pass Distance between the start and end points, shown as horizontal and
vertical values, measured in tenths of millimeters.
P１ Distance between the start point and bottom left corner of the pattern,
P１ ：measured in tenths of millimeters.
P２ Distance between the start point and top right corner of the pattern, P
１ ： measured in tenths of millimeters.
B The status time bar of the design being downloaded
6. When the download finishes, the screen will go back to the Start screen with the design
selected on the screen.
A
B
