7.14
CANopen
®
Type code BM3200, BM3300 with CANopen
®
:
BM3XXX-XXXX-XXXXX[-X]-3XXXX[-S0X]-XX[-XX][-EXX][-#XX]
X3
X4
CANopen
®
IN
CANopen
®
OUT
Memory 4 kByte DP-RAM, 256 kByte RAM, 
1 MByte Flash-EPROM
Number of bus connections 2, no slot rules
Bus connection 2 connectors RJ45, 8-pin
Baud rates 20/125/250/500/1000 kBit/s
Address range 7 Bit; address 1 to address 127
Address setting DIP-switch
Short-circuit proof RJ45-connection Yes
Isolation Optocoupler, DC/DC-converter
1: CAN_H
2: CAN_L
3: GND
4: reserved
5: reserved
6: GND
7: reserved
8: reserved
X3
X4
