102 Transceivers 6200 Series DV14307.03 Issue 06 February 2021
Four Seat Installation (no Tandem)
2.9.9.1 Configuration - Four Seat Installation (no Tandem)
Sub-Menu
Function/Selection
"SPKR VOLUME SOURCE
BOTH
"CONFIGURATION"
"SWAP MIKE IC" Disabled
"IN/OUT CFG1" (/MIKE_SW
open):
"MICROPHONE 1" STD1_MIKE
"MICROPHONE 2" STD3_MIKE
"BOTH MIKES" Enabled
"HEADPHONE 1" Disabled
"SPEAKER" Enabled
• If only headphone(s) are used, the speaker can be disabled by
selecting NONE.
• If only the speaker is used, HDPH 1 can be disabled.
• The standard microphone is selected for both configurations.
"IN/OUT CFG2"
(/MIKE_SW closed):
"MICROPHONE 1" STD1_MIKE
"MICROPHONE 2" STD2_MIKE
"BOTH MIKES" Disabled
"HEADPHONE 1" Enabled
"HEADPHONE 2" Enabled
"SPEAKER" Disabled
Remarks
• If PTT is active then is the speaker muted.
The external switch (J1-24 /MIKE_SW) works as follows:
• Open:
o Headset 1 and 2 for pilot and co-pilot selected.
o Headset 3 and 4 for passengers selected.
o The speaker is enabled.
o Intercom with VOX is not possible.
• Closed:
o Headset 1 and 2 for pilot and co-pilot selected.
o Headset 3 and 4 disconnected.
o The hand mike selected (STD3).
o The speaker is disabled.
o Intercom with VOX is possible.
