Becker RT6201 - Squelch; Scan Hold Time; Sidetone

Becker Avionics
Installation
Configuration Setup
DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 83
Squelch
Display Contents
Description
"SQUELCH THR":
Notice: The menu is available on the primary controller.
Notice: The "SQUELCH THR" is available with the "User Menu" at any time.
• Use the rotary encoder for the adjustment.
6...26
Minimum adjustment of 6 means:
• Weak RF signals can trigger the squelch threshold and the voice
signal might be low combined with a noisy background.
Maximum adjustment of 26 means:
• Only strong RF signals will trigger the squelch threshold. The voice
signal will be audible very clear with very low background noise.
• Weak RF signals may not trigger the squelch threshold and
therefore the audio may not be heard by the user.
Scan Hold Time
Display Contents
Description
"SCAN HOLD TIME":
Notice: The menu is available on the primary controller.
• Use the rotary encoder for the adjustment.
1...60 s
• The factory default adjustment is 1.
• For normal operation it is recommended to keep this adjustment
at 1.
Sidetone
Display Contents
Description
"SIDETONE ATT":
Notice: The menu is available on the primary controller.
• Use the rotary encoder for the adjustment.
0…12 dB
• The attenuation relates to the intercom volume.
o 0 dB = sidetone as loud as intercom signal.
o 12 dB = sidetone signal 12 dB less than the intercom
signal.
Example: If the intercom volume is set to a very low value, then the
sidetone volume is decreased in relation to the intercom volume,
irrespective of the sidetone value.
The "SIDETONE ATT" parameter is an additional attenuation of the
sidetone signal in transmit mode.
6
SQUELCH THR
1
SCAN HOLD TIME
6
SIDETONE ATT
