Becker RT6201 - Cable Harness

Becker Avionics
Installation
Aircraft Wiring
DV14307.03 Issue 06 February 2021 Transceivers 6200 Series 111
Cable Harness
2.9.12.1 Configuration - 1K065 for General Aviation
The IN/OUT CFG1 can be set from the user:
Display Contents
Description
"IN/OUT CFG1":
Notice: The menu is available on the primary controller.
Notice: "IN/OUT CFG1" is shown only when MIKE_SW input has active state (J1-24).
When MIKE_SW is connected both configurations CFG1 and CFG2 must be configured.
• On this page you can configure the microphone inputs and
headphone outputs for configuration CFG1.
• Select the option with the rotary encoder.
"MICROPHONE 1" (set only one of the options):
STD1 MIKE:
• Standard microphone input 1 is selected (P1-18/ P1-8).
STD2 MIKE:
• Standard microphone input 2 is selected (P1-9/ P1-8).
STD3 MIKE:
• Standard microphone input 3 is selected (P1-19/ P1-8).
DYN MIKE:
• Dynamic microphone input is selected (P1-6/ P1-5).
NONE:
• No microphone is used in microphone path 1.
"MICROPHONE 2" (set only one of the options):
STD1 MIKE:
• Standard microphone input 1 is selected (P1-18/ P1-8).
STD2 MIKE:
• Standard microphone input 2 is selected (P1-9/ P1-8).
STD3 MIKE:
• Standard microphone input 3 is selected (P1-19/ P1-8).
DYN MIKE:
• Dynamic microphone input is selected (P1-6/ P1-5).
NONE:
• No microphone is used in microphone path 2.
"MIC ACTIVATION"
BOTH MIKES ENABLED:
• Input /PTT1 starts transmission from microphone path 1 and 2
(P1-17).
• Input /PTT2 starts transmission from microphone path 2 and path 1
(J1-5).
• Input /IC starts intercom from microphone path 1 and 2 (P1-7).
BOTH MIKES DISABLED:
• Input /PTT1 starts transmission only from microphone path 1
(P1-17).
• Input /PTT2 starts transmission only from microphone path 2 (J1-5).
• Input /IC starts intercom only from microphone path 1 (P1-7).
"OUTPUTS"
HDPH 1 ENABLED:
• Audio is available on headphone 1 output (P1-2/P1-3).
HDPH 1 DISABLED:
• No audio is available on headphone 1 output.
MICROPHONE 1
● STD 1 MIKE
○ STD 2 MIKE
○ STD 3 MIKE
○ DYN MIKE
○ NONE
MICROPHONE 2
○ STD 1 MIKE
● STD 2 MIKE
○ STD 3 MIKE
○ DYN MIKE
○ NONE
MIC ACTIVATION
 BOTH MIKES
OUTPUTS
 HEADPHONE 1
○ HEADPHONE 2
○ SPEAKER
● NONE
IN/OUT CFG 1
